1. Identify Symbols on a Sample Blueprint

Blueprint Symbols Quiz

Instructions: Circle the correct answer for each question.

1. Which symbol represents a standard door?

A) ──|──

B) ⊗

C) ┌─┐

D) ⟶

2. What does this symbol represent? |__|

A) Window

B) Double Door

C) Shower

D) Sliding Door

3. Which of the following is a symbol for a Switch (single)?

A) ●

B) $

C) ⊖

D) ◯

4. The symbol ⊙ represents which electrical item?

A) Ceiling Fan

B) Phone Jack

C) 220v. Outlet

D) TV Outlet

5. Which symbol represents a bathtub?

A) □
